McDonnell F-101B Voodoo - Фото и видео

Макдоннелл F-101B Вуду
Страны	США
Роль	Сверхзвуковой реактивный истребитель
Первый полет	29 сентября 1954 года
Построен	807

Teh Макдоннелл F-101 Вуду was a supersonic jet fighter which served the United States Air Force (USAF) and the Royal Canadian Air Force (RCAF). Initially designed by McDonnell Aircraft as a long-range bomber escort (known as a penetration fighter) for the Strategic Air Command (SAC), the Voodoo was instead developed as a nuclear-armed fighter-bomber for the Tactical Air Command (TAC), and as a photo reconnaissance aircraft based on the same airframe. An F-101A set a number of world speed records for jet powered aircraft, including fastest airspeed, attaining 1,207.6 miles (1,943.4 km) per hour on 12 December 1957. They operated in the reconnaissance role until 1979.

Источник: Макдоннелл F-101B Вуду в Википедии

McDonnell F-101B Voodoo
Фотограф	Неизвестная
Локализации	Неизвестная
Фотографии	28

Макдоннелл F-101B Вуду 1

Макдоннелл F-101B Вуду 2

Макдоннелл F-101B Вуду 3

Макдоннелл F-101B Вуду 4

Макдоннелл F-101B Вуду 5

Макдоннелл F-101B Вуду 6

McDonnell F-101B Voodoo 7

McDonnell F-101B Voodoo 8

McDonnell F-101B Voodoo 9

Click on a photo and use the mouse scroll to view all photos

Подождите, поиск Макдоннелл F-101B Voodoo для вас ...

Купить мне кофе

McDonnell F-101B Voodoo Walk Around
Фотограф	Сес Хендрикс
Локализации	Неизвестная
Фотографии	121

Макдоннелл F-101B Вуду

Загрузить еще...

McDonnell RF-101C Voodoo
Фотограф	Джон Хек
Локализации	Неизвестная
Фотографии	77

CF-101B Voodoo Walk Around
Фотограф	Скотт Трембле
Локализации	Неизвестная
Фотографии	21

The Nuclear-Armed Interceptor

Teh F-101B Voodoo was the ultimate evolution of a design that started as a long-range bomber escort. When the Air Force realized it needed a powerful, all-weather interceptor to stop Soviet bombers from crossing the Arctic, they turned the Voodoo into a two-seat powerhouse. The “B” model was the most produced version, distinctive for its massive twin engines and its primary mission: carrying nuclear-tipped rockets. It was a “point-and-shoot” interceptor designed to fly fast, fly far, and erase entire bomber formations with a single blast.

Attribute	Technical Specification (F-101B)
Роль	Long-Range All-Weather Interceptor
Экипажа	2 (Pilot and Radar Intercept Officer)
Двигателей	2 × Pratt & Whitney J57-P-55 afterburning turbojets
Максимальная скорость	Mach 1.72 (1,825 km/h / 1,134 mph) at 35,000 ft
Service Ceiling	16,700 meters (54,800 feet)
Основное вооружение	2 × AIR-2A Genie nuclear rockets & 2 × AIM-4 Falcon missiles
Special Feature	Rotary Weapons Bay Door
Размах крыла	12.09 meters (39 ft 8 in)

Design Engineering: The Rotary Door & The Genie

The Rotary Weapons Door: To maintain its supersonic aerodynamics, the Voodoo carried its missiles on a unique “rotodoor.” The missiles were mounted on both sides of a flat panel that flipped 180 degrees to expose the weapons to the airstream just before firing, keeping the fuselage perfectly smooth.
The AIR-2 Genie: The F-101B was the primary carrier of the “Genie,” an unguided rocket with a 1.5-kiloton nuclear warhead. Because it was unguided, the pilot just had to get the Voodoo pointed in the general direction of a bomber fleet; the nuclear blast radius would do the rest.
The T-Tail & “Pitch-Up”: Like many early supersonic jets, the Voodoo had a T-tail (the horizontal stabilizer is on top of the fin). This led to a dangerous “pitch-up” tendency at high angles of attack, which could cause the plane to enter an unrecoverable spin—a quirk that pilots had to be extremely careful to manage.
The Searchlight: For night interceptions, some F-101Bs were fitted with a high-intensity spotlight on the left side of the fuselage to visually identify targets before engaging.

Operational History: Guarding the North

NORAD Sentinel: For much of the 1960s, the Voodoo was the backbone of Air Defense Command. It was designed to “scramble” within minutes to intercept intruders over the Atlantic, Pacific, and the North Pole.
The Canadian “Voodoo”: Canada operated 56 of these as the CF-101. They were a critical part of the joint US-Canadian defense strategy, serving until 1984 when they were finally replaced by the CF-18 Hornet.
The RF-101 “Recce” Legend: While the “B” model was an interceptor, the single-seat RF-101 reconnaissance version became a hero of the Cuban Missile Crisis and Vietnam. It was the first supersonic photo-recon jet, flying “low and fast” to bring back the proof of Soviet missiles in Cuba.
Thunderstorm Hunter: After its military retirement, one F-101B was used by Colorado State University for severe storm research. Because of its incredible structural strength, it was one of the few planes that could safely fly directly into the core of a thunderstorm to take measurements.
