Yakovlev Yak-18

Yakovlev Yak-18
Land	Sovjetunionen
Type	Trening fly
Introduksjon	1946
Status	I begrenset tjeneste

Den Yakovlev Yak-18 (russisk: Яковлев Як-18; NATO-kallenavn Max) var et sovjetisk tandem toseters militært primærtreningsfly. Opprinnelig drevet av en 119 kW (160 hk) Shvetsov M-11FR-1 stjernestempelmotor, ble den tatt i bruk i 1946. Den er også produsert i Kina som Nanchang CJ-5.

Kilde: Yakovlev Yak-18 på Wikipedia

Yakovlev Yak-18 gå rundt
Fotograf	Vladimir Yakubov
Lokalisering	Pacific Coast Dream Maskiner
Bilder	97

Yak-18 01

Yak-18 02

Yak-18 03

Yak-18 04

Yak-18 05

Yak-18 06

Yak-18 07

Yak-18 08

Yak-18 09

Click on a photo and use the mouse scroll to view all photos

Vent, Søker Yakovlev Yak-18photos for deg ...

Yakovlev Yak-18 gå rundt
Fotograf	Vladimir Yakubov
Lokalisering	Planes of Fame Museum, Chino
Bilder	43

Yakovlev Yak-18 01

Yakovlev Yak-18 02

Yakovlev Yak-18 03

Yakovlev Yak-18 04

Yakovlev Yak-18 05

Yakovlev Yak-18 06

Yakovlev Yak-18 07

Yakovlev Yak-18 09

Yakovlev Yak-18 08

Click on a photo and use the mouse scroll to view all photos

Nanchang CJ-5 Gå rundt
Fotograf	Vladimir Yakubov
Lokalisering	Salinas Air Show
Bilder	54

Nanchang CJ-55 01

Nanchang CJ-55 02

Nanchang CJ-55 03

Nanchang CJ-55 04

Nanchang CJ-55 05

Nanchang CJ-55 07

Nanchang CJ-55 06

Nanchang CJ-55 08

Nanchang CJ-55 09

Click on a photo and use the mouse scroll to view all photos

Les også:

The Gateway to the Red Air Force

Den Yakovlev Yak-18 was the primary basic trainer for the Soviet Air Force and civilian DOSAAF flying clubs for decades. Introduced in 1946 to replace the legendary but aging Po-2 biplane, it was designed to be rugged, forgiving, and easy to maintain. While it looked like a simple trainer, it was the aircraft that shaped the skills of nearly every Soviet pilot of the early Cold War—including Yuri Gagarin, the first human in space.

Attribute	Technical Specification (Yak-18 Early Variant)
Rolle	Primary Trainer / Liaison
Mannskapet	2 (Student and Instructor in tandem)
First Flight	1946
Kraftverk	1 × Shvetsov M-11FR 5-cylinder radial
Horsepower	160 hp (119 kW)
Maximum Speed	154 mph (248 km/h)
Service Ceiling	13,120 feet (4,000 m)
Construction	Metal frame with fabric and metal skin

Design Evolution: From Taildragger to Tricycle

The M-11 “Helmeted” Engine: The original Yak-18 used the classic Shvetsov M-11 radial engine. It was easily recognizable by the individual “helmet” fairings over each cylinder head, designed to provide cooling while reducing drag.
The Yak-18A Upgrade: As Soviet jet fighters moved to tricycle landing gear (nose-wheel), the Yak-18 was redesigned as the **Yak-18A**. It featured a much more powerful engine and a nose-wheel configuration to better prepare students for modern jets.
Pneumatic Systems: In a distinctively Soviet design choice, the Yak-18 used compressed air (pneumatics) rather than hydraulics to operate its landing gear, flaps, and brakes. This made it reliable in extreme Siberian winters where hydraulic fluid might freeze or leak. [Image diagram of the Yak-18 pneumatic system layout for landing gear and flaps]
Mixed Construction: To save weight and strategic materials, the rear fuselage and wings were fabric-covered over a metal frame, while the forward fuselage was metal-skinned for durability near the engine.

A Global Legacy and “Night Witch” Roots

Gagarin’s First Wing: Yuri Gagarin learned to fly in a Yak-18 at the Saratov Aero Club. He famously returned to visit his old flight instructor after his historic spaceflight, crediting the Yak-18’s honest handling for his foundational skills.
Combat in Korea: Although a trainer, the North Korean Air Force used Yak-18s (alongside Po-2s) for “Bedcheck Charlie” night raids. Flying low and slow at night, they were nearly impossible for US jet interceptors to track on radar or shoot down.
The Chinese CJ-6: The Yak-18 was licensed to China, where it evolved into the Nanchang CJ-6. While heavily modified with an all-metal flush-riveted skin and a different wing profile, its DNA remains rooted in the Yakovlev design.
Acrobatic Pedigree: The success of the Yak-18 led directly to the Yak-18P Og Yak-18PM, world-championship-winning single-seat aerobatic aircraft that dominated international competitions in the 1960s.
