M3A5 赠款 II | |
|---|---|
| 国家 | 美国 |
| 类型 | 中型坦克 |
| 描述 | 专辑 117 照片走动坦克«M3A5格兰特II» |
M3A5 赠款 II 的照片库， 中型坦克M3 was an American tank used during World War II. In Britain the tank was called by two names based on the turret configuration. Tanks employing US pattern turrets were called the “General Lee”, named after Confederate General Robert E. Lee. Variants using British pattern turrets were known as “General Grant”, named after U.S. General Ulysses S. Grant. Design commenced in July 1940, and the first M3s were operational in late 1941.
源： 维基 百科
| M3A5 GRANT Walk Around | |
|---|---|
| 摄影师 | Unknow |
| 本地化 | 军车技术基金会 |
| 照片 | 74 |
