M3A5 Επιχορήγηση II | |
|---|---|
| Χώρα | Ηπα |
| Πληκτρολογήστε | Μεσαία δεξαμενή |
| Περιγραφή | Άλμπουμ του 117 φωτογραφίες περιμετρικά δεξαμενής «M3A5 Grant II» |
Φωτογραφίες ενός M3A5 Grant II, το Μεσαία δεξαμενή M3 was an American tank used during World War II. In Britain the tank was called by two names based on the turret configuration. Tanks employing US pattern turrets were called the “General Lee”, named after Confederate General Robert E. Lee. Variants using British pattern turrets were known as “General Grant”, named after U.S. General Ulysses S. Grant. Design commenced in July 1940, and the first M3s were operational in late 1941.
Πηγή: Wikipedia
| M3A5 GRANT Walk Around | |
|---|---|
| Φωτογράφος | Unknow |
| Εντοπισμού | Ίδρυμα Τεχνολογίας Στρατιωτικών Οχημάτων |
| Φωτογραφίες | 74 |
