Dornier Do-24

Dornier Do-24
Zemlja	Nacistička Nemačka
Ulogu	Bombarder, izviđački i vazdušno-morski spasilački leteći čamac
Prvi let	3. jul 1937.
Izgradio	279

Čaj Dornier Do 24 je 1930-ih nemački tromotorni leteći čamac dizajniran od strane Dornier Flugzeugverke za pomorsku patrolu i traganje i spašavanje. Prema Dornier evidenciji, neki 12.000 ljudi su spaseni od strane Do 24s tokom svoje karijere letenja. Ukupno 279 izgrađeno je među nekoliko fabrika od 1937. do 1945. godine.

Izvor: Dornier Do-24 na Vikipediji

Dornier Do-24 Walk Around
Fotograf	Meindert de Vreeze
Lokalizacija	Nepoznato
Fotografije	39

Dornier Do-24 01

Dornier Do-24 02

Dornier Do-24 03

Dornier Do-24 04

Dornier Do-24 05

Dornier Do-24 06

Dornier Do-24 07

Dornier Do-24 08

Dornier Do-24 09

Click on a photo and use the mouse scroll to view all photos

Čekajte, Searching Dornier Do-24 za vas...

Časti me kafom

Dornier Do 24K Walk Around
Fotograf	Nepoznato
Lokalizacija	Nepoznato
Fotografije	49

Dornier Do-24 Walk Around
Fotograf	Moris Sagius
Lokalizacija	Nepoznato
Fotografije	29

Dornier Do-24

Učitaj još...

Pogledajte i:

A Dutch Design with a German Heart

Čaj Dornier Do 24 was an exceptionally seaworthy flying boat originally designed for the Dutch Naval Air Service (MLD) to protect the East Indies. When Germany occupied the Netherlands in 1940, production continued for the Luftwaffe. It became famous for its incredible durability in rough water, often landing in heavy seas to rescue downed airmen that other flying boats could not reach. It was so successful that it remained in service for decades after the war, notably with the Spanish Air Force for Search and Rescue (SAR).

Attribute	Technical Specification (Do 24T)
Ulogu	Maritime Reconnaissance / Search and Rescue (SAR)
Posada	6
First Flight	July 3, 1937
Powerplant	3 × Bramo 323R-2 Fafnir 9-cylinder radials
Horsepower	1,000 hp (746 kW) per engine
Maksimalna brzina	210 mph (340 km/h)
Opseg	1,800 miles (2,900 km)
Naoružanje	1 × 20mm Hispano-Suiza cannon; 2 × 7.92mm MG 15 machine guns

Unique Maritime Engineering

The “Sponson” Stability: Instead of using wing-mounted floats that could easily break in rough waves, Dornier used “stub-wings” or sponsons protruding from the hull. These provided lateral stability on the water and acted as boarding platforms for rescued crews.
Triple-Engine Reliability: The three engines were mounted on a parasol wing high above the fuselage to keep the propellers clear of sea spray. The center engine was positioned slightly higher than the outer two to further reduce water ingestion during takeoff.
The “Two-Step” Hull: The underside of the fuselage featured a sophisticated “stepped” design. This broke the suction of the water during takeoff, allowing the heavy boat to “unstick” and transition to flight much faster in choppy conditions.
Broad-Tail Fin: The twin-tail design was specifically chosen to provide excellent directional control during water taxiing and to remain clear of the heavy engine exhaust and wake.

Combat Service & Humanitarian Legacy

Čaj Seenotdienst: During WWII, the Do 24 was the backbone of the German Sea Rescue Service. It is estimated that Do 24 crews rescued over 12,000 airmen from the sea throughout the conflict, often operating under fire.
Spanish Service: Spain operated the Do 24 until the late 1960s. Their aircraft were painted in bright yellow and green “SAR” colors and were legendary among Mediterranean sailors for their ability to land in almost any weather.
The Do 24 ATT: In the early 1980s, a surviving hull was fitted with modern turboprop engines and a new wing. This “Amphibian Technology Testbed” (ATT) proved the timeless efficiency of the original hull design.
Seaworthiness: While the American PBY Catalina was more numerous, many historians and pilots consider the Do 24 to be the finest open-ocean flying boat ever built due to its superior hull strength and rough-water handling.
