USS Cod |
|
|---|---|
| Land | Norge , Norge |
| Rolle | Undervannsbåt |
| Lansert | 21. mars 1943 |
| Ikke i bruk | 15. desember 1971 |
Kilde: USS Torsk på Wikipedia
| USS Cod SS-224 Walk Around | |
|---|---|
| Fotograf | Bill Maloney |
| Lokalisering | Unknow |
| Bilder | 477 |
Les også:
General Characteristics and Role
The USS Cod (SS-224) is a Gato-class submarine of the United States Navy, built during World War II. The Gato-class represented the first mass-produced fleet submarines designed for long-range patrols in the Pacific. The Cod conducted seven war patrols against Japanese forces, sinking 12 enemy vessels and earning seven battle stars. She is one of the most famous surviving US submarines, recognized for a unique action in July 1945 when her crew rescued 48 Dutch and Indonesian sailors and airmen from the grounded Dutch submarine O-19 in the South China Sea. Unable to transfer the large number of rescued men to a ship, the Cod successfully communicated with the O-19’s crew and, when the Dutch sub could not be freed, sank it with torpedoes before sailing to safety. The Cod is now a museum ship in Cleveland, Ohio.
| Property | Typical Value (Gato-Class) |
|---|---|
| Rolle | Fleet Submarine (World War II) |
| National Origin | USA |
| Builder | Electric Boat Company (Groton, Connecticut) |
| Bestilt | 21 June 1943 |
| Displacement (Surfaced) | 1,526 long tons (1,550 t) |
| Displacement (Submerged) | 2,424 long tons (2,463 t) |
| Length Overall | 95.02 m (311 ft 9 in) |
| Beam | 8.31 m (27 ft 3 in) |
| Test Depth | 90 m (300 ft) (Later increased) |
| Mannskapet | 6 officers, 54 enlisted men |
Powerplant and Performance
- Powerplant (Surfaced): 4 x General Motors 16-278A V16 diesel engines driving four main electric generators.
- Powerplant (Submerged): 4 x Electric motors driving two propeller shafts.
- Shaft Horsepower: 5,400 shp (Surfaced); 2,740 shp (Submerged).
- Maximum Speed: 20.25 knots (37.5 km/h) surfaced; 8.75 knots (16.2 km/h) submerged.
- Endurance: 11,000 nautical miles at 10 knots surfaced.
Armament and Modern Status
- Torpedo Tubes: 10 x 21-inch (533 mm) torpedo tubes (6 bow, 4 stern).
- Torpedo Load: Up to 24 torpedoes (usually a mix of Mark 14 steam-driven and Mark 18 electric torpedoes).
- Deck Guns (Original): 1 x 4-inch (102 mm) / 50 cal deck gun and various smaller anti-aircraft guns (.50 cal, 20 mm).
- Post-War Status: Decommissioned in 1946 and later used as a reserve training ship. Fully decommissioned in 1971.
- Museum Ship: The USS Cod has been docked in Cleveland, Ohio, since 1976 and is one of the best-preserved WWII submarines, still retaining its internal equipment largely intact.
