ATR 42

ATR 42
Maa	Ranska/Italia
Rooli	Potkuriturbiinikone Alueellinen matkustajakone
Ensimmäinen lento	16. elokuuta 1984
Rakennettu	500+

Nniiden ATR 42 on ranskalais-italialaisen valmistajan ATR:n valmistama alueellinen matkustajakone, jonka loppukokoonpano on Toulousessa, Ranskassa. Lentokone lanseerattiin 4. marraskuuta 1981 ATR:n kanssa ranskalaisen Aérospatialen (nykyisin osa Airbusia) ja Aeritalian (nykyinen Leonardo S.p.A.) yhteisyrityksenä.

Lähde: ATR 42 Wikipediassa

ATR 42-300 Kävele ympäriinsä
Valokuvaaja	Vladimir Jakubov
Lokalisointi	Capital Air Show 2012, Sacramento, Kalifornia
Valokuvat	150

ATR 42-300 001

ATR 42-300 002

ATR 42-300 003

ATR 42-300 004

ATR 42-300 005

ATR 42-300 006

ATR 42-300 007

ATR 42-300 008

ATR 42-300 009

Click on a photo and use the mouse scroll to view all photos

Odota, etsitään ATR 42:ta sinulle...

Osta minulle kahvia

Katso myös:

Genesis of a Commuter Icon

The ATR 42-300 was the initial production version of the ATR 42 family, a joint venture between France’s Aérospatiale (now Airbus) and Italy’s Aeritalia (now Leonardo). First entering service in 1985 with Air Littoral, the -300 was designed specifically for the short-haul regional market. It filled a critical niche for an aircraft that was more efficient than pure jets on short hops while offering better passenger comfort than older generation turboprops. Its success laid the foundation for ATR becoming the world’s leading manufacturer of regional turboprop aircraft.

Property	Standard Specification (ATR 42-300)
Rooli	Regional Airliner / Short-haul Transport
miehistö	2 Pilots + 1 or 2 Flight Attendants
Passenger Capacity	42 to 50 seats
Voimalaitos	2 x Pratt & Whitney Canada PW120 turboprops
Horsepower	2,000 shp (1,491 kW) per engine
Enimmäisnopeus	491 km/h (305 mph / 265 knots)
Maximum Range	approx. 1,600 km (860 nmi) with full payload
Siipiväli	24.57 meters (80 ft 7 in)

Engineering and Operational Features

Korkeasiipinen muotoilu: The high-wing configuration allows for a low-to-the-ground fuselage, facilitating easy passenger boarding and cargo loading without the need for complex airport stairs or high-lift loaders.
Propeller Brake (Hotel Mode): A unique feature of the ATR is the ability to run the right-hand engine (No. 2) with a propeller brake engaged while on the ground. This allows the engine to provide electrical power and air conditioning to the cabin without the prop spinning, acting as a built-in APU.
Pratt & Whitney PW120: The -300 was powered by the PW120, a rugged and reliable engine that utilized a two-spool concept, which significantly improved fuel efficiency compared to earlier turboprop designs.
Short-Field Performance: Engineered for versatility, the -300 can operate from runways as short as 1,100 meters, making it ideal for connecting remote communities with major hubs.

Variants and Evolution

ATR 42-320: A minor upgrade to the -300 that featured improved PW121 engines for better “hot and high” performance (operations at high altitudes or in high temperatures).
Cargo Conversions: As they aged out of passenger service, many -300s were converted into freighters (ATR 42-300F), featuring a large cargo door on the forward port side.
The Legacy Lineage: The -300 was eventually succeeded by the -400, -500, and the current -600 series, which introduced glass cockpits, six-bladed propellers, and even more efficient engines.

Service Legacy

Global Adoption: The ATR 42-300 saw massive success in Europe, North America, and Southeast Asia, with major operators including FedEx (Feeder), American Eagle, and Olympic Airways.
Luotettavuus: Many original -300 series aircraft remained in active service for over 30 years, speaking to the durability of the airframe and the simplicity of its mechanical systems.
