P-40 radar | |
| Country | Soviet Union |
| Type | Radar |
| Photograph | Vladimir Yakubov |
| Locate | War Machinery and Transport Museum |
| Description | Album of 139 photos walk-around of «P-40 radar» |
Photo gallery of a P-40 radar, The P-40 “Armour” or 1S12 (also referred to by the NATO reporting name “Long Track” in the west) is a 3-D UHF radar developed and operated by the former Soviet Union.
Source: P-40 radar on Wiki
Buy Me a CoffeeSee also:
The P-40 radar, also known as 1S12 or Long Track by NATO, was a 3-D UHF radar developed and operated by the former Soviet Union in the 1960s. It was designed to provide early warning and target acquisition for anti-aircraft systems such as the 2K11 Krug. The P-40 radar had a high mobility and could be deployed on a tracked chassis powered by a diesel engine. The radar used an open frame parabolic antenna with a stacked beam feed to scan the azimuth and determine the elevation angle of the targets.
The P-40 radar had a range of 370 km and a power of 2 MW. It was operated by a crew of six and had a gas turbine generator to supply electricity. The P-40 radar was one of the first radars to enter service with the new tactical anti-aircraft forces of the Soviet armed forces and was later passed down to successor states after the fall of the Soviet Union.
