ATS-59G-tykistötraktori
Maa	URSS
Tyyppi	Tykistötraktori
Kuvaus	Galleria 190 kuvia ATS-59G-tykistötraktori

Kuvagalleria ATS-59G-tykistötraktorista, The Artilleriyskiy Tyagach Sredniy 59 eli ATS-59 (eli keskitykistötraktori) oli Neuvostoliiton kylmän sodan aikainen tykistötraktori.

Lähde: ATS-59G-tykistötraktori

Paino: 13 000 kg pituus: 6,28 m leveys: 2,78 m korkeus: 2,3 m Moottori: diesel 300hv Toiminta-alue: 350 km nopeus: 45 km/h

ATS-59G Artillery Tractor 064

ATS-59G Artillery Tractor 065

ATS-59G Artillery Tractor 066

ATS-59G Artillery Tractor 067

ATS-59G Artillery Tractor 068

ATS-59G Artillery Tractor 069

ATS-59G Artillery Tractor 070

ATS-59G Artillery Tractor 071

ATS-59G Artillery Tractor 072

Click on a photo and use the mouse scroll to view all photos

Odota, Etsi ATS-59G Tykistö Traktori valokuvia sinulle ...

Osta minulle kahvia

Tractor Artillery ATS-59
Valokuvaajat	Ei tietää
Lokalisointi	Ei tietää
Valokuvat	12

ATS-59 01

ATS-59 02

ATS-59 03

ATS-59 04

ATS-59 05

ATS-59 06

ATS-59 07

ATS-59 08

ATS-59 09

Click on a photo and use the mouse scroll to view all photos

Katso myös:

General Overview

Designation	Artilleriyskiy Tyagach Sredniy – 59G (Medium Artillery Tractor – 59G)
Place of Origin	Neuvostoliiton
Entry into Service	Late 1950s/Early 1960s (ATS-59); ATS-59G improved variant later
Primary Role	Towing heavy artillery (e.g., 130 mm M-46 gun, 152 mm howitzers) and transporting crew/supplies.
Crew & Passengers	7 (including driver) in the large cab
Design Basis	Utilizes many components, including the engine and running gear, of the T-54 Main Battle Tank.

Technical Specifications (ATS-59G)

Mass (Empty)	Approx. 13.5 tonnes
Moottori	A-650 V-12 water-cooled diesel (a throttled version of the T-54’s V-2 engine)
Engine Power	300 hp at 1,700 rpm
Max Towed Load	Asti 14 tonnia
Payload Capacity	3.0 tonnes (on the cargo platform)
Top Speed (Road)	Approx. 39–45 km/h
Toiminta-alue	350 km (500 km with auxiliary tanks)
Key Feature	Equipped with a powerful mechanical winch (15-ton capacity).

ATS-59G Improvements

The original ATS-59 had a small two-person cab. The ATS-59G was developed to address this and featured a significantly larger, fully enclosed cab, which could seat up to 7 people (driver + 6 passengers). This allowed the entire artillery crew to be transported with the piece they were towing, rather than sitting exposed on the cargo platform.

Additionally, the ‘G’ model included an NBC (Nuclear, Biological, Chemical) overpressure system for crew protection.
