Ba-3

BA-3

Ország URSS
Típus Nehéz páncélozott autó
Fénykép Vlagyimir Yakubov
Téma

Album 102 képek egy tank BA-3

The BA-3 (Russian: Broneavtomobil 3) was a heavy armored car developed in the Soviet Union in 1933, followed by a slightly changed model BA-6 in 1936. Both were based mostly on BA-I, the most important development being the new turret, same as in the T-26 m 1933 and BT-5 tanks, and also equipped with the 45 mm main gun. Around 180 BA-3 cars were built at the Izhorskij and Vyksunskij factories, until production ended in 1935. BA-6 followed with 386 cars produced between 1936 and 1938 in Izhorskij factory. Most of BA-3 production was based on the Ford-Timken chassis, a 6×4 modification of the US Ford AA 4×2 truck, but the last batch was built on Russian version of the same chassis – GAZ-AAA, continued to be used in BA-6. The biggest limitation of the BA-3 was the mobility, limited to roads or very hard ground, the result of unnecessarily[1] large weight. The innovation that slightly improved mobility were the auxiliary (“Overall”) tracks that could be fitted onto the rear tandem wheels, converting the car to half-track.

Forrás: BA-3 a Wikipédián

Wait, Searching BA-3 photos for you…
Wait, Searching BA-3 for you…

Műszaki adatok
Weight : 5.82t
Length : 4.65m
Width : 2.10m
Height : 2.20m
Crew : 4
Armor : 15mm turret, 9mm hull
Main armament : 45 mm 20-K gun (60 rounds)
Secondary armament : 2×7.65 DT
Operational range : 260km
Speed : 63km/h
